| Brand Name : | Hi-Target |
| Model Number : | V30 |
| Certification : | CE FC |
| Price : | 1-10$/set |
| Delivery Time : | Within 10 working days |
| Payment Terms : | L/C,T/T,Western Union |
| Supply Ability : | 100 Sets per Week |
Fast Survey High Performance Wifi Digital Satellite Receiver
It is designed to meet high quality standards at an affordable price. It is outstanding in its
class, with a rugged design and user-friendly functions.
V30 GPS is equipped with a smart speaker guiding the whole operation.Multi one-button functions make fieldwork easier,
such as auto base setup by one button,The rover can get fix solution once it is turned on.
Seamless operation in CORS system,Built-in GPRS/GSM/3G module ensures that the V30 works perfectly with network RTK positioning.
IP67 dust/water protection. Withstands 3-meter natural fall onto concrete.
Rapid tracking and perfect avoidance or reduction of obstruction and multipath effect to ensure superior positioning capability.
The picture of Wifi Digital Satellite Receiver
What's the advantage of our Wifi Digital Satellite Receiver?
Independence: No external cable or battery is needed, so you can put it where you want.
Compatibility: It can both directly transmit and forward in same-frequency or pilot-frequency
Multi-channel: It has 116 UHF channels, and supports custom channels.
Power: 5W/10W/20W/35W adjustable
Distance:Its max working distance is 50 km, which depends on the setting altitude.
Resistant features: waterproof, dustproof, broken-resistant performance.Intelligentialized self-diagnosis function
| ||||
Measurements | 220 tracking channels | |||
Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology | ||||
High precision multiple correlator for GNSS pseudo range measurements | ||||
Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response | ||||
Very low noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth | ||||
Signal-to-Noise ratios reported in dB-Hz | ||||
Proven Pacific Crest low elevation tracking technology | ||||
Satellite signals tracked simultaneously | GPS: Simultaneous L1C/A, L2C, L2E, L5 | |||
GLONASS: Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P | ||||
SBAS: Simultaneous L1 C/A, L5 | ||||
Galileo: Simultaneous L1 BOC, E5A, E5B, E5AltBOC | ||||
BDS: B1, B2 | ||||
QZSS: L1 C/A, L1 SAIF, L2C, L5 | ||||
Positioning Accuracy | Static and Fast Static GNSS surveying | Horizontal: 2.5mm+0.5ppm RMS Vertical: 5mm+0.5ppm RMS | ||
Stop & Go GNSS surveying | Horizontal: 1cm+1ppm RMS Vertical: 2.5cm+1ppm RMS Initialization time: typically 10 minutes for base while 5 minutes for rover Initialization reliability: typically > 99.9% | |||
Realtime Kinematic(RTK) surveying | Horizontal: 8mm+1ppm RMS Vertical: 15mm+1ppm RMS Initialization time: typically < 8 seconds Initialization reliability: typically > 99.9% | |||
Code Differential GNSS positioning | Horizontal: 25cm+1ppm RMS Vertical: 50cm+1ppm RMS SBAS[iv]:0.50mHorizontal,0.85m Vertical | |||
Hardware | Physical | 1.Dimensions (W x H): 19.50cm x 10.40cm(7.68 in x 4.09 in) 2.Weight: 1.3kg (2.86lb) with internal battery, internal radio, standard UHF antenna 3.Operating temperature: -45℃to +65℃(-49℉to +149℉) 4.Storage temperature: -55℃to +85℃(-67℉to +185℉) 5.Humidity: 100%, considering 6.Water/dustproof: IP67 dustproof, protected from temporary 7.immersion to depth of 1m (3.28ft). 8.Shock and Vibration: Designed to survive a 3m(9.84ft) natural fall onto concrete. 9.Storage: 64M | ||
Electrical | 1.Power 6V to 28V DC external power input 2.Power consumption 2.5W 3.Automatic Switching between internal power and external power 4.Rechargeable, removable 7.4V, 5000mAh Lithium-Ion battery in internal battery compartment 5.Internal battery life, Static 13 - 15 hours, RTK Rover (UHF/GPRS/3G) 10 - 12 hours and RTK Base 8 - 10 hours | |||
Communication | GPRS/GSM or 3G | Fully integrated, fully sealed internal GPRS/GSM or 3G Network RTK (via CORS) range20-50km | |
HI-TARGET internal UHF radio (standard) | Frequency: 460 MHz with 116 channels Transmitting Power: 0.1W, 1W, 2W adjustable Transmitting Speed: Up to 19.2Kbps Working Range: 3~5Km typical, 8~10km optimal | ||
PacificCrest XDL micro Internal UHF Radio (Optional) | Frequency: 403~473 MHz Transmitting Power: 0.5W, 1.0W, 2.0W adjustable Transmitting Speed: Up to 19.2Kbps Support most of radio communication protocol Working Range: 3~5km typical, 8~10km optimal | ||
HI-TARGET External UHF radio (standard) | Frequency: 460 MHz with 116 channels Transmitting Power: 5W, 10W, 20W, 30W adjustable Transmitting Speed: Up to 19.2Kbps Working Range: 8~10Km typical, 15~20km optimal | ||
Pacific Crest ADL Vantage Pro External UHF radio (Optional) | Frequency: 390~430 MHz or 430~470 MHz Transmitting Power: 4W to 35W adjustable Transmitting Speed: Up to 19.2Kbps Support most of radio communication protocol Working Range: 8~10Km typical, 15~20km optimal | ||
